10AWG Solar Cable with Mc4 Connectors
ICHYTI Company is a professional manufacturer of 10 awg solar cable. Through continuous research and development work, we have become a leading manufacturer in this field. We have multiple series of products to choose from. If you are interested in any of our products, please feel free to contact us or send us an email, and we will be happy to provide you with more detailed information.
Send Inquiry PDF DownLoad
Product Description
"Based on domestic market and expand abroad business" is our enhancement strategy for 10AWG Solar Cable with Mc4 Connectors, We welcome all with the shoppers and buddies to call us for mutual rewards. Hope to do further more business along with you.
10AWG Solar Cable with Mc4 Connectors Solar Panel Cable, Solar PV Cable, Solar Cable 6mm2, Our product quality is one of the major concerns and has been produced to meet the customer's standards. "Customer services and relationship" is another important area which we understand good communication and relationships with our customers is the most significant power to run it as a long term business.
China Manufacturers ICHYTI Cheap Durable 10AWG Solar Cable with Mc4 Connectors is used to connect photovoltaic modules to combiner boxes, with a simple structure. It uses polyolefin insulation material, which has excellent heat resistance, cold resistance, oil resistance, and UV resistance. It can be used in harsh environmental conditions and has a certain degree of mechanical strength. This type of 10AWG Solar Cable with Mc4 Connectors can be protected through conduit, using photovoltaic module brackets as channels and fixing points for cable layout, thereby reducing the impact of environmental factors.
◉ The maximum temperature of the wire is 120 ℃ (duration 20000 hours) according to IEC/EN 60216-1 standard.
◉ The short-circuit temperature of the cable is 200 ℃ and the duration is 5 seconds.
◉ The cable meets the EN 60216-2 standard (temperature index+120 ° C) through thermal durability test.
◉ The cable meets the EN 60811-3-1 standard through high-temperature pressure test.
◉ The cable has moisture and heat resistance, meets the EN 60068-2-78 standard, and has a humidity of 85%.
2. Try to shorten the length of the cable as much as possible while meeting safety requirements.
3. Cable laying and maintenance should be convenient.
4. Avoid cable laying in areas that are about to be excavated.
5. At any turning point in any laying method and path, the cable should meet the allowable bending radius requirements.
ICHYTI 10AWG Solar Cable with Mc4 Connectors Parameter (Specification)
|
Type |
Cross Section |
Strand design |
Conductor diameter |
Conductor resistance |
Outer diameter Ax B |
Rated voltage |
Rated current |
|
mm2 |
No.xq)(mm) |
mm |
Q/km |
mm |
VAC/DC |
A |
|
|
PV-1x2.5mm2 |
2.5 |
50 x(p0.25 |
2.0 |
8.06 |
5.3 |
1000/1800 |
30 |
|
PV-1x4.0mm2 |
4.0 |
56 x(p0.3 |
2.6 |
4.97 |
6.4 |
1000/1800 |
50 |
|
PV-1x6.0mm2 |
6.0 |
84 x(p03 |
3.3 |
3.52 |
7.2 |
1000/1800 |
70 |
|
Wire |
Class 5, tinned |
|
Insulation Material |
XLPE |
|
Double Insulated |
|
|
Halogen-free |
|
|
High resistance against oils, greases, oxygen |
|
|
and ozone |
|
|
Microbe-resistant |
|
|
UV Resistant |
|
|
High Wear And Abrasion Resistance |
|
|
Flam Test According To |
DIN EN 50265-2-1 UL1571(VW-1) |
|
Smallest Permissible Bending Radius |
5XD |
|
Temperature Range |
-40℃~ +90℃ |
|
Colours |
Black/red |
ICHYTI 10AWG Solar Cable with Mc4 Connectors Feature
◉ The maximum voltage of the cable is suitable for an ambient temperature range of -40 ℃ to+90 ℃.◉ The maximum temperature of the wire is 120 ℃ (duration 20000 hours) according to IEC/EN 60216-1 standard.
◉ The short-circuit temperature of the cable is 200 ℃ and the duration is 5 seconds.
◉ The cable meets the EN 60216-2 standard (temperature index+120 ° C) through thermal durability test.
◉ The cable meets the EN 60811-3-1 standard through high-temperature pressure test.
◉ The cable has moisture and heat resistance, meets the EN 60068-2-78 standard, and has a humidity of 85%.
ICHYTI 10AWG Solar Cable with Mc4 Connectors Details and structure
ICHYTI 10AWG Solar Cable with Mc4 Connectors Selection regulations
1. Ensure that the cable is free from mechanical external forces, overheating, corrosion, and other hazards.2. Try to shorten the length of the cable as much as possible while meeting safety requirements.
3. Cable laying and maintenance should be convenient.
4. Avoid cable laying in areas that are about to be excavated.
5. At any turning point in any laying method and path, the cable should meet the allowable bending radius requirements.
